SM 600
Automatic Spring Snap Button Attaching Machine |
|
 |
|
|
* Spring snap and ring snap
are not allowed to be used simultaneously
* For example, other
snaps cannot be used with goods produced
* by spring snap
* Snap applicable to machine can be produced upon
the customer¡¯s
* requirement. |
|
 |
 |
|
|
 |
|
* One machine
can work for spring (ring) snap buttons of 12 mm, 13 mm,
14 mm, 15 mm sizes.
* Equipped with a punching machine that enables the use
of weak chalk
* Motor specifications: 1) 220 V. 1P (50/60 HZ). 0.25
KW (main machine)
* Motor specifications: 2)
220 V. 1P (50/60 HZ). 0.06 KW (punching machine)
* Dimensions: 500 mm * 400 mm * 1,300 mm ¡¿ 2 units
* Weight: 90 kg ¡¿ 2 units |
|
 |
|
| |
|
|
