SM 888-P
All One Hot-Fix Setting Machine by Ultrasonic & Electric System |
|
 |
|
|
|
| |
 |
 |
|
|
| |
 |
|
* Equipped with
both ultrasonic and electric system (heater).
* Equipped with two trays and versatile for various usage
and easy operation.
* Easy one-touch shifting between ultrasonic and heater
systems.
* Equipped with all functions of SM888-N and SM888-H.
* Attaching speed: 20-130 pcs/min.
* Applicable fabric: denim, polyester, cotton, silk, others.
* Applicable clothes: jeans, T-shirt, women¡¯s wear, underwear,
belt, bag, cap, accessories, label, children¡¯s wear, etc.
* Power: AC 220V. 1-PH (50/60 HZ)
* Air pressure: 5-6 kg/mm
* Applicable size: 2.0-6.0 mm
* Dimensions: 600 mm * 550 mm * 1,200 mm
* Weight: 65 kg
* Air compressor: 5 HP |
|
 |
|
| |
|
|
